Power Rating
-
- Power Range
- 65/75/99/118 ekW @ 1800 rpm (60 Hz), 65/80/99 ekW @ 1500 rpm (50 Hz)
-
Engine Specifications
-
- Emissions
- U.S. EPA Tier 3 certified, EU Stage V certified
- Configuration
- In-line 4, 4-stroke-cycle diesel
- Rated Engine Speed
- 1500/1800 rpm
- Bore
- 4.13in
- Stroke
- 5in
- Displacement
- 268in³
- Aspiration
- Turbocharged-aftercooled and turbo only aspiration (Turbocharged aspiration only for 65ekW (71bkW))
- Governor
- Electronic (A5 ECM)
- Refill Capacity
- Lube Oil System w/Oil filter change: 11 L 2.8 gal)
- Oil Change Interval
- 500 hrs
- Cooling
- Heat exchanger, combined circuit keel cooling, or separate circuit keel cooling
- Flywheel Housing
- SAE No. 03 with SAE 11.5 flywheel (126 teeth)
-
Dimensions & Weights
-
- Maximum Length
- 80.2in
- Maximum Height
- 78.7in
- Maximum Width
- 38.3in
- Maximum Engine Dry Weight
- 3389lb
Standard Equipment:
-
Cooling System
-
- Gear-driven jacket-water and auxiliary water pumps
- Engine mounted air cleaner and expansion tank
- Integral plate-type oil cooler
-
Exhaust System
-
- Watercooled exhaust manifold and turbocharger
-
Fuel System
-
- Common Rail fuel system
-
Lube System
-
- Open crankcase ventilation system
-
Mounting System
-
- Engine mounted fuel and oil filter
- Engine mounted customer interface and control relays
-
Starting System
-
- 12V or 24V starter motor
-
General
-
- 3-phase AREP generators with 300% short circuit capability
- Digital Automatic Voltage Regulator
- Class H generator insulation
Optional Equipment:
-
General
-
- MGGP 200 Gauge Panel and interface harness
- Engine shutdown sensors and shutdown controller
- Double wall high pressure fuel lines
- EMCP engine control panel
- MGCP II engine control panel
- AC Voltage Monitoring
- Glow plugs
- Factory installed generator space heater kit
- MCS Certifications
