Models
Units:
C4.4 (Electronic Control System)
Power Range
65/75/99/118 ekW @ 1800 rpm (60 Hz), 65/80/99 ekW @ 1500 rpm (50 Hz)
Emissions
U.S. EPA Tier 3 certified, EU Stage V certified
Configuration
In-line 4, 4-stroke-cycle diesel
C1.5 Marine Generator Set Engine
Minimum Rating
10 ekW (10 kVA)
Maximum Rating
13 ekW (16.5 kVA)
Frequency
50 Hz or 60 Hz
Cat C2.2 Marine Generator Set
Minimum Rating
16 ekW (16kVA)
Maximum Rating
27 ekW (27 kVA)
Frequency
50 Hz or 60 Hz
Cat® C4.4 Marine Generator Set
Minimum Rating
36.0R ekW (45 kVA)
Maximum Rating
99.0 ekW (123 kVA)
Frequency
50 Hz or 60 Hz
Cat C7.1 Generator Set
Minimum Rating
100 ekW (125 kVA)
Maximum Rating
200 ekW (250 kVA)
Frequency
50 Hz or 60 Hz
C9.3 Marine Generator Set
Minimum Rating
185R ekW (231 kVA) at 50hz, 224R ekW (280 kVA) at 60hz
Maximum Rating
250R ekW (313 kVA) at 50hz, 300 ekW (375 kVA) at 60hz
Frequency
50 Hertz & 60 Hertz
C18 (SRMP) Marine Generator Set
Minimum Rating
260 ekW (325 kVA)
Maximum Rating
565 ekW (706 kVA)
Frequency
50 hz
Cat C32 ACERT Generator Set (IMO II)
Minimum Rating
550 eKW (688 kVA)
Maximum Rating
940 ekW (1175 kVA)
Frequency
50 Hz or 60 Hz
Cat C32 ACERT Generator Set (EPA Tier 3)
Minimum Rating
730 ekW (913 kVA)
Maximum Rating
940 ekW (1175 kVA)
Frequency
60hz
Cat C32 Generator Set (US EPA Tier 3 / IMO II)
Minimum Rating
219 ekW
Maximum Rating
940 ekW
Frequency
60hz
Cat C32 Generator Set (IMO III)
Minimum Rating
219 ekW
Maximum Rating
940 ekW
Frequency
60hz
3512C High Displacement Marine Generator Set
Minimum Rating
1550 eKW (1937 kVA)
Maximum Rating
1700 eKW (2125 kVA)
Frequency
60 hz
Cat C280-6 Marine Generator Set
Minimum Rating
1760 ekW (2200 kVA)
Maximum Rating
1820 ekW (2275 kVA)
Frequency
50 Hz or 60 Hz
Cat C280-8 Marine Generator Set
Minimum Rating
2350 ekW (2938 kVA)
Maximum Rating
2420 ekW (3025 kVA)
Frequency
50 Hz or 60 Hz
Cat C280-12 Marine Generator Set
Minimum Rating
3520 ekW (4400 kVA)
Maximum Rating
3640 ekW (4550 kVA)
Frequency
50 Hz or 60 Hz
